KUKA 00-331-410 Machine Frame Mounting – KR IONTEC
Article No. 331410
Allen screws with lock washers are used for fastening it to a machine frame. A cylindrical pin and a flat-sided pin are provided to ensure correct positioning. The machine frame mounting is used for installing positioners on a mounting surface prepared by the customer or on an adapter plate (optional).
SPECIFICATIONS:
331410
Package includes:
- 1x Flat-sided locating pin 20×25 00-119-652
- 1x Cylindrical locating pin 20×15 66-044-320
- 8x Hexagon bolt M20x60 55-874-386
- 8x 21x45x5 conical spring washer 57-750-756
Suitable for:
- KR 20 R3100 (334944)
- KR 30 R2100 (332113)
- KR 50 R2100 (332115)
- KR 50 R2100 HO (372998)
- KR 50 R2500 (334818)
- KR 50 R2500 F (361189)
- KR 50 R2500 HO (394138)
- KR 70 R2100 (332117)
- KR 70 R2100 F (361186)
- KR 70 R2100 HO (409431)
CONDITION: NEW
$362.00
