FANUC A16B-3200-0731/A05B-2600-H002 Main PCB – R30iB

SPECIFICATIONS:

• Main Board/PCB for Fanuc R-30iB Controllers.
  • Force Sensor Option
  • See Alternate Main Boards for other options
• The main board is an important component that stores the robot’s programs and configurations. It also controls servo mechanism positioning.
• Contains: microprocessor, peripheral circuits, memory, and operator’s panel control circuit.
• There are various cards and module options that may be installed horizontally to the main board.
  • See Related Parts (below) for card options
  • or see R-30iB Main PCB Card & Module Reference Guide for more information
• FANUC Ordering Specification #: A05B-2600-H002

Please note this main board has been discontinued by the Fanuc and replaced with a new version: A16B-3200-0781

CONDITION: USED

Related Parts:

Alternate R-30iB Main Boards:
A16B-3200-0730 or A16B-3200-0780 (Standard Option)
A16B-3200-0732 or A16B-3200-0782 (Force sensor, High Speed Communication Option)

CPU Card Options:
A20B-3300-0686 or A17B-3301-0106 (SDRAM 32MB)
A20B-3300-0687 or A17B-3301-0107 (SDRAM 64MB)
A20B-3300-0688 or A17B-3301-0108 (SDRAM 128MB)

Axis Control Card Options:
A20B-3300-0664 or A20B-3300-0774 (6-Axis)
A20B-3300-0663 or A20B-3300-0773 (12-Axis)
A20B-3300-0662 or A20B-3300-0772 (18-Axis)
A20B-3300-0661 or A20B-3300-0771 (24-Axis)
A20B-3300-0660 or A20B-3300-0770 (36-Axis)

FROM/SRAM Module Options
A20B-3900-0283 or A20B-3900-0297 (FROM 32MB/ SRAM 1MB)
A20B-3900-0284 or A20B-3900-0298 (FROM 32MB/ SRAM 2MB)
A20B-3900-0285 or A20B-3900-0299 (FROM 32MB/ SRAM 3MB)
A20B-3900-0286 (FROM 64MB/ SRAM 1MB)
A20B-3900-0287 (FROM 64MB/ SRAM 2MB)
A20B-3900-0288 (FROM 64MB/ SRAM 3MB)
A20B-3900-0280 (FROM 128MB/ SRAM 1MB)
A20B-3900-0281 (FROM 128MB/ SRAM 2MB)
A20B-3900-0282 (FROM 128MB/ SRAM 3MB)
